Beta 390 RR 2023
Enduro / Trail / Dual Sport
386cc
4-stroke
279lb
wet weight
37in
Seat height
11.8in
Front travel
6spd
Gearbox
The machine
The 2023 Beta 390 RR is an off-road four-stroke motorcycle powered by a 386 cc, single-cylinder engine with electronic fuel injection, two injectors and liquid cooling. It pairs a six-speed transmission with a 9-liter fuel tank and long-travel suspension: a 48 mm upside-down fork with 300 mm of wheel travel and a rear setup with 295 mm of wheel travel. The listed running-order weight is 126.5 kg with a full tank and optional equipment. A 940 mm seat height and 320 mm ground clearance are useful figures to consider when checking fit and suitability for uneven terrain.
The chassis uses a 21-inch front wheel and an 18-inch rear wheel, with a 260 mm front disc and 240 mm rear disc. The RR 350–390–430–480 manual covers both Standard and Race Edition versions, so equipment details can vary by edition.
Who should ride it
This bike fits riders looking for a full-size, off-road-focused four-stroke with a six-speed gearbox and substantial suspension travel. It is a practical match for weekend trail riders and off-road riders covering varied terrain, including rough or muddy tracks where ground clearance and suspension travel matter. The 940 mm seat height and 126.5 kg running-order weight are important fit and handling considerations, especially for newer riders or anyone frequently maneuvering the bike at a standstill.
Garage
Tech specs
- Displacement
- 386cc
- Stroke
- 4-stroke
- Fuel system
- Fuel injection
- Bore × stroke
- 88 × 63.4 mm
- Compression
- 12.5:1
- Torque
- 23.6 ft-lb
- Cooling
- Liquid
- Configuration
- Single-cylinder
- Valve train
- DOHC
- Valves
- 4
- Oil chamber
- Dual
- Engine oil
- 0.75 L
- Oil type
- 10W-50
- Coolant
- 1.3 L
- Type
- Wet multiplate
- Actuation
- Hydraulic
- Assist
- Manual
- Spring
- Diaphragm
- Starting
- Electric
- Transmission
- 6-speed
- Front sprocket
- 13T
- Rear sprocket
- 49T
- Wet weight
- 278.9 lb
- Seat height
- 37″
- Ground clearance
- 12.6″
- Wheelbase
- 58.7″
- Width
- 32.2″
- Height
- 50″
- Fuel capacity
- 2.38 gal
- Front
- 48 mm open-cartridge hydraulic upside-down fork
- Front travel
- 11.8″
- Rear
- Single shock absorber with progressive linkage
- Rear travel
- 11.6″
- Front wheel
- 21″
- Rear wheel
- 18″
- Front tire
- 90/90-21
- Rear tire
- 140/80-18
- Front disc
- 260 mm
- Rear disc
- 240 mm
- Skid plate
- Yes
- Radiator fan
- No
- Street legal
- Yes
- Battery
- Yes
- Chemistry
- Lithium
- Voltage
- 12V
Pit-lane questions
- 01
How much does the 2023 Beta 390 RR weigh?
Its listed running-order weight is 126.5 kg, with a full fuel tank and optional equipment. The listed distribution is 61.8 kg at the front and 64.7 kg at the rear.
- 02
What engine does the 2023 Beta 390 RR have?
It has a 386 cc, single-cylinder, four-stroke engine with electronic fuel injection and a double injector. The cooling system uses forced liquid circulation by pump.
- 03
How much fuel does the 2023 Beta 390 RR hold?
The fuel tank capacity is 9 liters, including a 2.5-liter reserve.
- 04
What is the seat height of the 2023 Beta 390 RR?
The seat height is 940 mm. Ground clearance is 320 mm.
- 05
What oil does the 2023 Beta 390 RR use?
The specified engine oil is 10W-50. Normal maintenance capacity is 750 ml; capacity after a complete engine review is 800 ml.
- 06
How many gears does the 2023 Beta 390 RR have?
It has a six-speed transmission and a wet, multidisc clutch.
- 07
What are the tire sizes on the 2023 Beta 390 RR?
The specified front tire is 90/90-21 and the rear is 140/80-18. The wheels are 21 inches at the front and 18 inches at the rear.
- 08
How much suspension travel does the 2023 Beta 390 RR have?
The front wheel travel is 300 mm, and the rear wheel travel is 295 mm. The rear shock absorber travel is 135 mm.
