Line 'em
up
250CC
450CC
250CC
Displacement
250 cc
450 cc
250 cc
Weight
223.8 lbWin
228 lb
280 lb
Seat height
37.2 in
37.6 in
—
Ground clearance
13.2 in
13.5 in
—
Front travel
12 in
12.2 inWin
10.7 in
Rear travel
11.5 in
11.8 in
—
Wheelbase
58.7 in
58.8 in
56.1 in
Fuel capacity
1.9 gal
2.09 gal
2.25 galWin
MSRP
—
$10,399
—
Displacement250cc450cc250cc
Stroke4-stroke4-stroke4-stroke
Fuel systemFuel injectionFuel injectionFuel injection
Bore × stroke81 × 48.5 mm95 × 63.4 mm77 × 53.6 mm
Compression14.5:113.6:111.2:1
CoolingLiquidLiquidLiquid
ConfigurationSingle-cylinderSingle-cylinderSingle-cylinder
Valve trainDOHCSOHCDOHC
Valves444
Oil chamberSingleSingle—
Engine oil1 L1.2 L1.8 L
Oil type10W-5010W-5010W-30 / 10W-40 / 15W-40 / 20W-40 / 20W-50
Coolant0.9 L0.95 L1.5 L
TypeWet multiplateWet multiplateWet multiplate
ActuationHydraulicHydraulicCable
AssistManualManualManual
Spring——Coil
StartingElectricElectricElectric
Transmission5-speed5-speed6-speed
Chain size520520520
Chain links——112
Front sprocket14T13T13T
Rear sprocket51T51T—
Wet weight——280 lb
Dry weight223.8 lb228 lb—
Seat height37.2″37.6″—
Ground clearance13.2″13.5″—
Wheelbase58.7″58.8″56.1″
Width——32.1″
Height——46.6″
Fuel capacity1.9 gal2.09 gal2.25 gal
Frame materialChromolyChromolyChromoly
ArchitectureCentral tubeCentral tubePerimeter
Rake26.1°26.1°25°
Steering angle——45°
FrontWP XACT AER air forkWP XACT AERTelescopic hydraulic fork
Front travel12″12.2″10.7″
RearWP XACT LDS shockWP XACT LDSAdjustable hydraulic shock absorber with linkage
Rear travel11.5″11.8″—
Front wheel21″21″21″
Rear wheel19″19″18″
Front tire80/100-21 TL80/100-21 M/C 51M TT90/90-21
Rear tire110/90-19 TL110/90-19 M/C 62M TT140/80-18
Front disc260 mm260 mm260 mm
Rear disc220 mm220 mm220 mm
Map switchYesNoYes
Skid plate—NoYes
Radiator fanNoNoYes
Street legalNoNoYes
BatteryYesYesYes
OEM batteryHJTZ5S-FP-C—GS YTX9-BS
ChemistryLithiumLithiumLead acid
Voltage12V12V12V
Capacity2 Ah—3 Ah
