Honda CRF250F 2020
Trail
249cc
4-stroke
265lb
Curb weight
34.8in
Seat height
8.5in
Front travel
5spd
Gearbox
About the Honda CRF250F 2020The machine
The 2020 Honda CRF250F is an off-road trail bike with a 249 cc, air-cooled, fuel-injected four-stroke single-cylinder engine. Its SOHC four-valve engine pairs with a five-speed transmission, cable-operated manual clutch and electric start. The steel perimeter frame carries a 41 mm telescopic fork with 8.5 inches of travel and a Pro-Link Showa rear shock with 9.1 inches of travel and adjustable spring preload.
It has a 34.8-inch seat height, 11.3 inches of ground clearance and a 265-pound curb weight. The 1.59-gallon fuel tank, 21-inch front wheel and 18-inch rear wheel suit trail riding. This off-road-only motorcycle was offered in red, with a $4,599 U.S. MSRP plus a $190 destination charge.
Who should ride it
This bike is for riders whose main use is recreational trail riding on off-road routes. Its five-speed transmission, electric start and 34.8-inch seat height are useful considerations when choosing a trail motorcycle; check the seat height against your inseam and riding comfort. It is not a street-legal choice in the United States, and its listed riding category is trail rather than motocross or road use. The CRF250F is designed for one rider, with no passenger capacity.
Honda CRF250F 2020 photosGarage
Honda CRF250F 2020 specificationsTech specs
- Displacement
- 249cc
- Stroke
- 4-stroke
- Fuel system
- Fuel injection
- Bore × stroke
- 71 × 63 mm
- Compression
- 9.6:1
- Cooling
- Air
- Configuration
- Single-cylinder
- Valve train
- SOHC
- Valves
- 4
- Engine oil
- 1.4 L
- Oil type
- 10W-30
- Actuation
- Cable
- Assist
- Manual
- Starting
- Electric
- Transmission
- 5-speed
- Chain size
- 520
- Front sprocket
- 13T
- Rear sprocket
- 50T
- Seat height
- 34.8″
- Ground clearance
- 11.3″
- Wheelbase
- 55.9″
- Width
- 31.5″
- Height
- 46.7″
- Length
- 83.1″
- Curb weight
- 265 lb
- Fuel capacity
- 1.59 gal
- Destination charge
- $190
- Colors
- Red
- Warranty
- Six Months, Transferable limited warranty. Extended coverage available with a Honda Protection Plan.
- Electric starter
- Standard
- Fuel injection
- Standard
- Spark arrester
- Standard
- Maintenance-free battery
- Standard
- Frame material
- Steel
- Architecture
- Perimeter
- Rake
- 26.1°
- Trail
- 4″
- Front
- 41mm telescopic fork
- Front travel
- 8.5″
- Rear
- Pro-Link Showa single shock with spring-preload adjustability
- Rear travel
- 9.1″
- Front wheel
- 21″
- Rear wheel
- 18″
- Front tire
- 80/100-21 51R NHS
- Rear tire
- 100/100-18 59R NHS
- Front disc
- 240 mm
- Rear disc
- 220 mm
- Street legal (US)
- No
- Road legal in
- None
- Battery
- Yes
- OEM battery
- YTZ7S
- Chemistry
- Lead acid
- Voltage
- 12V
- Capacity
- 6 Ah
Honda CRF250F FAQPit-lane questions
- 01
Is the 2020 Honda CRF250F street legal?
No. It is an off-road-only motorcycle and is not street legal in the United States. It is not equipped with lights and has a bank-angle sensor ignition cut-off system.
- 02
What engine does the 2020 Honda CRF250F have?
It has a 249 cc, air-cooled, fuel-injected four-stroke single-cylinder engine with SOHC and four valves. The compression ratio is 9.6:1.
- 03
How much oil does a 2020 Honda CRF250F take?
Oil capacity is 1.5 US qt after draining, including after an oil-filter change; capacity after engine disassembly is 1.8 US qt. The specified viscosity is SAE 10W-30.
- 04
What is the seat height and weight of the 2020 Honda CRF250F?
Seat height is 34.8 inches and curb weight is 265 lb.
- 05
How much fuel does the 2020 Honda CRF250F hold?
The fuel tank holds 1.59 US gal, including a 0.34-gallon reserve. The fuel recommendation is unleaded gasoline with a pump octane number of 86 or higher.
- 06
What suspension travel does the 2020 Honda CRF250F have?
The front suspension has 8.5 inches of travel, and the rear suspension has 9.1 inches. The rear Pro-Link Showa shock has spring-preload adjustability.
- 07
What tires and wheels come on the 2020 Honda CRF250F?
It has a 21-inch front wheel with an 80/100-21 51R NHS tire and an 18-inch rear wheel with a 100/100-18 59R NHS tire. The specified cold tire pressure is 15 psi front and rear.
- 08
What is the 2020 Honda CRF250F MSRP?
The U.S. MSRP is $4,599, with a $190 destination or freight charge. Its manufacturer warranty is a transferable six-month limited warranty.
